Complex Number Matrices

Objective

We show how to perform matrix operations involving complex numbers in Excel. We consider two different formats. On this webpage, we discuss how to perform these operations using Real Statistics format, while in Complex Matrices in Excel Format we describe these operations on matrices in complex numbers in text format “a + bi“.

We represent an m × n matrix of complex numbers by an m × 2n range in Excel. This range consists of an m × n range on the left and another m × n range on the right. The first of these ranges represents the real parts of the values of the complex numbers in the complex number matrix. The second of these ranges represents the imaginary parts of the complex numbers in the complex number matrix.

For example, the complex number matrix

image277z

can be represented by the Excel range B13:E14 shown in Figure 1.

Complex matrix Excel

Figure 1 – Complex matrix in Excel

The left side in yellow (range B13:C14) contains the real values and the right side in green (range D13:E14) contains the imaginary values.

Essentially, we are expressing a complex matrix as A + Bi where A and B are matrices that only have real values.

Matrix addition, subtraction, multiplication, and inverse on complex matrices are calculated using only real matrix operations, as follows:

image278z

image279z

Complex Matrix Product

image281z

Note that the formula for the inverse of a complex matrix requires that both the real part A and imaginary part B be invertible.

Worksheet Functions

Real Statistics Functions: The Real Statistics Resource Pack supplies the following array functions where Z is a range that represents a complex matrix and R and C are arrays that represent real-values matrices.

ZReal(Z) = the real part of the complex matrix Z

ZImag(Z) = the imaginary part of the complex matrix Z

ZSet(R, C) = the complex matrix whose real part is R and whose imaginary part is C

The Real Statistics Resource Pack also supplies the following array functions, where Y and Z are ranges that represent complex matrices, while z is a range that represents a complex (scalar) number and k is a positive integer.

Complex matrices functions

Note that ZIdentity(k) outputs a k × k identity matrix. If k is omitted it defaults to the number of rows in the highlighted range. ZIndex(Z, r, c) returns the complex number in the rth row and cth column of Z. ZConj(Z) returns a matrix of the same size and shape as Z but with every element replaced by the conjugate of that element.

ZLen(V) = the length of the column vector V, i.e. the square root of the sum of the squared absolute values of the entries in V. ZNorm(Z) = the matrix all of whose columns are the normalized versions of the columns in Z (i.e. column vectors divided by their length).

Examples

In Figures 2, 3, and 4, we show the results of various complex matrix operations.

Complex matrix operations 1

Figure 2 – Complex Matrix Operations – part 1

Complex matrix operations 2

Figure 3 – Complex Matrix Operations – part 2

Complex matrix operations 3

Figure 4 – Complex Matrix Operations – part 3

Examples Workbook

Click here to download the Excel workbook with the examples described on this webpage.

References

Wolfram (2016) Complex matrix
https://mathworld.wolfram.com/ComplexMatrix.html

Brenner, S. C., Kaup, D. J. (1999) Introduction to complex numbers
https://control.dii.unisi.it/sistdin-SI/complex.pdf
